Chint 125A Automatic Transfer Switch – NXZ-125/4B

Model: NXZ-125/4B

Rated Current: 125A

Poles: 4 Poles

Rated Voltage: 400V AC

Frequency: 50/60Hz

Transfer Type: Automatic

Switching Time: ≤3 seconds

Control Mode: Automatic & Manual

Contact Type: Silver alloy contact

Protection Features:

Overload protection
Short circuit protection
Under-voltage and over-voltage protection

Mechanical Life: 10,000+ operations

Operating Temperature Range: -25°C to +70°C

Enclosure Material: High-quality, flame-retardant plastic

Mounting: Surface or DIN rail mountable

The Chint 125A Automatic Transfer Switch (NXZ-125/4B) is designed to automatically transfer the load between the main power source and backup generators, ensuring uninterrupted power supply. With its robust construction and reliable switching mechanism, this device is ideal for residential, commercial, and industrial applications where continuous power is essential. The switch operates seamlessly during power outages, preventing any disruptions in critical operations.
